       Hollow Spindle CNC/ Manual Lathes From Dial



CNC Lathes

2400 Series

In the tradition of providing high quality and rugged machinery, Dial brings you one of the most versatile CNC turning centers that won't bust your budget.

The Dial DC2000 and DC2400 Series are lathes that give you the versatility of a hollow spindle lathe, configured to operate in either manual or CNC mode.

To obtain this versatility we combine the hand controls of a manual tool room lathe with the unsurpassed automation that only a CNC turning center can provide. Together, these wonderful lathes give you the versatility and precision needed to obtain the finest professional results.

Currently, these units are shipped with either a  Fagor or Funuc, (your choice) controller installed.

Specifications DC-2000 Series DC-2400 Series Weights and Measures DC-2000 Series DC-2400 Series

Swing over bed

20" (500mm)

24" (610mm)

Dimensions (L X W X H)
All Models



33" center to center
107" X 67" X 78"

52" center to center
126" X 67" X 78"

75" center to center
148" X 67" X 78"



60" center to center
140" X 72" X 84"

80" center to center
160" X 72" X 84"

120" center to center

200" X 72" X 84"



Swing over Slide

11.5" (292mm)

16" (400mm)

Swing over Gap

28" (710mm)

31" (800mm)

Length of gap

12" (305mm)

15.3" (390mm)

Width of bed

13" (330mm)

17.7" (450mm)

Spindle bore

3.312" (85mm)

4.125" (105mm)

Spindle Speed
(No,) and range

Infinitely variable
30--2000 RPM
(3 ranges)

Infinitely variable
22-1500 RPM
(3 ranges)

Weights
All Models

33" center to center
5940 lbs

52" center to center
6800 lbs

75" center to center
7260 lbs



60" center to center
7920 lbs

80" center to center
9020 lbs

120" center to center
11000 lbs



Feed Rate

X axis 0-250 IPM (0-8350 mm/min)
Z axis 0-400 IPM (0-1000 mm/min)

Tailstock - Quill diameter

3" (75mm)

3" (75mm)

Tails stock- Quill travel

6.25" (160mm)

8.8" (225mm)

X axis servo

1.4 HP

1.4 HP

Z axis servo

1.4 HP

2.7 HP

Spindle Motor HP

15 HP

20 HP

All Specifications are subject to change
